Blog Updates

I decided, having some free time, to finally update this blog and look at how it works.

Motivation

My goal for this blog is to keep in running as long as possible as cheaply as possible. The low traffic it generates means that the use case fits really well with AWS Lambda for pricing. To leverage this the site is built using Next.js and Serverless.js to run on Lambda. However I also wanted a way to save blog data without having to pay for and maintain a database while also ensuring I had a local copy of everything, and I also wanted full control of the site content so an off the shelf solution like Hugo didn't fit well.

So I decided to leverage S3 to act as both my file store, and my "database" for listing blog posts. I needed a way to know what posts there were and sort them in order of time posted.

I also wanted to be able to serve images:

Bird having fun with a mirror, an example of the important images I can now put on my blog.

Bird having fun with a mirror, an example of the important images I can now put on my blog.

Retrieving Blog Posts

The blog retrieving an index of posts by calling an AWS lambda function that returns a manifest.json file from S3. The manifest.json file contains metadata for every blog post on the site.

Here's an example of manifest.json :

[
  {
    "key":"28f18583-d389-4598-84e0-ebf9810ba2fd",
    "date":1515650723000,
    "title":"Image Test",
    "url":"image-test-please-ignore",
    "summary":"Testing images please ignore"
  },
  {
    "key":"2e64df10-41b7-4b68-885a-34dc9f0d043c",
    "date":1515650723000,
    "title":"Making Digglesby.com",
    "url":"making-digglesby-com-isomorphic-react-next-js",
    "summary":"An adventure through isomorphic web development."
  },
  {
    "key":"e1795d22-05e9-43ab-a4bc-ecd5e194e5b6",
    "date":1515565711000,
    "title":"Hello World",
    "url":"hello-world",
    "summary":"Welcome my blog! I will mostly be posting about my personal projects here, aswell as general things I find interesting."
    }
  ]

key here is a reference to an S3 folder at https://blog.digglesby.com

Because every file is served behind a Cloudfront CDN, assets are cached by browsers, so posts need to be able to be invalidated easily and effectively. My solution to this was to serve the manifest.json through a lambda function since the manifest.json file needs to be revalidated every time and be served from the same location, and have the tool invalidate post data by renaming their listing in manifest.json and directory in S3.

The Upload Tool

Every blog post is stored locally on my machine as /posts. Every post directory contains post.md /media and meta.json.

post.md is the post text as markdown

/media is a directory containing all images or files used in the post.

meta.json is a JSON file containing all metadata such as the URL slug, the title of the post, the date it was posted ect.

The post upload tool:

Maps each post to a unique "CACHE_ID" (a unique string that can be reset to invalidate any caching)

Generates resized versions of all images in /media for optimization

Generates a post.json file which combines the data from meta.json and the text from post.md

Saves all files locally to /bin

Syncs /bin to an S3 bucket to upload

Closing thoughts

While this setup is a little bizarre and fairly work intensive, the overall cost of the blog is nearly entirely usage based (with the exception of the domain name and email service), and very cheap.

You can take a look at the projects here: https://github.com/digglesby/digglesby-blog https://github.com/digglesby/digglesby-blog-posts

Making Digglesby.com

A story about how I made this project far harder than it should have been

I have been sitting on the domain digglesby.com and have been wanting to build a personal website for a while. With winter break coming up it gave me an opportunity to both finally build a personal blog but also learn more Isomorphic React and CouchDB.

The First Attempt

My starting point was my Isomorphic React Template which I made after getting tired of writing the same Babel and Webpack configs just to get something isomorphic to work with react router.

The template uses isomorphic-webpack to handle the server side render. It works by spinning up a V8 Virtual Machine with a context similar to a browser's for each render. Upside to this is that the code is truly isomorphic; code running on the server is running near exactly the same to the code running on the client.

However isomorphic-webpack's consistency comes at the expense of easily getting data from the VM running react to the server, compounded by the fact that isomorphic-webpack only waits long enough for the first render() call before unloading the VM. Roughly, this means that for components that need to be preloaded from a database (like this blog) can't easily call the API from the VM context or signal what the server should preload.

The way I solved this was to hard map each URL to an API call as needed.

import pathToRegexp from 'path-to-regexp';
import APIService from './APIService';

class URLPreloadingService{

  constructor(){
    this.urlMap = {
      '/':[
        function( keys ){

          return {
            url:"/posts",
            method:"get",
            data:null
          };
        }

      ],
      '/post/:posturl':[

        function( keys ){

          return {
            url:"/post/" + keys.posturl,
            method:"get",
            data:null
          };
        }

      ]
    };
  }

  ...

  preloadURL( path ){

    return new Promise(function(resolve, reject){
      let match = this.matchPath( path );

      if (match){
        let requests = this.getPreloadRequests(match);

        APIService.preloadPage(requests, match).then(function(){
          resolve();
        });
      }else{
        resolve();
      }
    }.bind(this));
  }
}

APIService here is just a class that makes returns a promise for all of the AJAX requests. The preloadURL promise MUST resolve before isomorphic-react loads the page in order for all the the react elements to have their data on render.

However, in order to maintain consistency between the server and client when hydrating every preloaded AJAX response has to be embeded in the server response somehow, that's where StatePreservationService comes in!

class StatePreservationService{

  constructor(){
    this.params = {};

    if (typeof window !== 'undefined'){
      if (window.dehydratedState != undefined){
        this.params = window.dehydratedState;
      }
    }

    this.get = this.get.bind(this);
    this.put = this.put.bind(this);
    this.dehydrate = this.dehydrate.bind(this);
    this.clear = this.clear.bind(this);
  }

  get(key){
    if (this.params.hasOwnProperty(key)){
      return this.params[key];
    }else{
      return null;
    }
  }

  put(key,value){
    this.params[key] = value;
  }

  dehydrate(){
    return "<script>window.dehydratedState="+JSON.stringify(this.params)+";</script>";
  }

  clear(){
    this.params = {};
    window.dehydratedState = this.params;
  }
}

Essentially StatePreservationService is a dumb store for json data with a dehydrate function that loads it into a script tag for HTML rendering, all preloaded requests from APIService are stored here.

import StatePreservationService from './services/StatePreservationService';
import URLPreloadingService from './services/URLPreloadingService';

function renderServer(){
  return {
    component:renderToString((
      <StaticRouter context={window} location={window.location.pathname}>
      <Routes />
      </StaticRouter>
    )),
    state:StatePreservationService.dehydrate
  };
}

if (typeof ISOMORPHIC_WEBPACK === 'undefined') {

	...

}else{

  app = new Promise(function(resolve,reject){
    URLPreloadingService.preloadURL(window.location.pathname).then(function(){

      resolve(renderServer());
    });
  });
}

export default app;

This is the entry point for isomorphic-webpack's evalBundleCode. You might notice the dehydrate function from StatePreservationService this is to work around the restraints in talking from the VM to Server.

server.get('*', (req, res) => {
  const requestUrl = req.protocol + '://' + req.get('host') + req.originalUrl;

  const bundle = evalBundleCode(requestUrl).default;

  bundle.then((app) => {
    const body = app.component;
    const state = app.state();
    const helmet = Helmet.renderStatic();

    if (app.get("HTTP_CODE")){
      res.status( app.get("HTTP_CODE") );
    }

    res.send(renderFullPage(body,helmet,state));
  });
});

Finally we have the actual express entry for rendering the page, and we call the renderStatic function and load it into the renderFullPage function that returns an html string from a template.

An important thing to know as well is that the StatePreservationService can store more than just AJAX responses, for example the little quote widget on the header randomly picks a quote in the component and stores it for the client render.

Ultimately the solutions to both of these issues are SUPER hacky and are far overbuilt for what they need to do. The need to load in every URL's AJAX calls makes expanding the site difficult and tedious.

The Second Attempt

When I had finally hacked together the isomorphic-webpack version to a point I found acceptable, I found a talk on Next.js which seemed to solve alot of the problems I was having in a much easier way.

For example making an AJAX request from a component goes from:

Having to defining each request by URL, preloading that request, and having the component check if it's waiting on a new AJAX request or getting a preloaded response in the old system.

To this in Next.js:

static async getInitialProps(context){
  const { url } = context.query;
  const res = await fetch(`${CONFIG.API_URL}/posts`);
  const resp = await res.json();

  return {
    initialPosts: resp.posts,
    maxPages: resp.pages
  }
}

AJAX requests become REALLY easy in Next.js thanks to this. The only issue is that Next.js only preloads data like this for components in the /pages directory meaning that you can't, for example, put this directly onto a blog feed object, the page it's self would have to pass the initial posts to it as props.

Next.js is also very adherent to the React architecture which makes traversing the virtual DOM upwards to relay data to the server difficult.

For example, the quotes component can't randomly pick its own quote anymore since in order to maintain consistency between server and client it would have to pass it's quote outside of the virtual DOM to the server, or somehow directly insert itself into Next's page preload data ( If there's a way to do this I've overlooked please let me know ). Instead of this I had every page pick a random number and pass it down the DOM to the quotes component.

It's still a hack but much more manageable than the previous attempt, plus it adds flavor to the site.

Closing Thoughts

Honestly, for what it is, I wish I had found Next.js sooner, it prevents a massive amount of headache and confusion when it comes to setting up an Isomorphic React app. I would be afraid to know how much time I've wasted setting up webpack and babel configs just to try and work my way around them to pass the wget test. However, I still think that there is still some benefit to the old model of isomorphic-webpack, or compiling two different webpack builds for server and client just due to the flexibility of how you can set up the render call.

But for quick apps, or if I had to build Digglesby.com again, I would definitely choose Next.js.

Thanks for reading!

At the time of writing I haven't added comments yet, but if you want to get in contact me please feel free to use my form. Or message me on twitter @digglesby

Hello World

Hello and welcome my blog! I will mostly be posting about my personal projects here, aswell as general things I find interesting.

I just finished writing this website with Next.js and CouchDB, so I'll be posting about that very soon.
